Lighting Control
16A Square Programmable Twilight Adjustable Day/Night Switch
Overview
• Photoelectric-Cell technology • UV Stabilised • IP66 Weatherproof Rating • Adjustable Lux & Time-on Settings • User Friendly Setup • Stainless Steel Captive Screws • LED Mode Indicator • Large Terminals • Heavy Duty Switching Capacity • Multiple Cable Entry Options • HPM-type base - Compatible with base units from other leading brands for retrofit applications • 5-year warranty
Product Details
SPECIFICATIONS
- Materials: Lens - UV stable acrylic, Fixings - Stainless steel
- Weatherproof rating: IP66
- Switch rating: 16 Amps
- Voltage rating: 200 - 250V
- Frequency: 50/60Hz
- Rated current: Resistive - 15 Amps, Inductive - 3600VA
- Switching cycles on resistive load: > 200,000
- Volt drop after 1000c at 1800VA load: < 100mV
- Adjustable switching lux level: 3 - 500 Lux
- Adjustable time-on setting: 1 - 9 hours
- Minimum load: 100mA
- Dimensions:
- 82.5mm (H) x 82.5mm (W) x 54.5mm (D)
SKU Details
| SKU | Description | MOQ | Units | CTN |
| FSW-12220 | 16A HDAD Square Programmable Twilight Adjustable Day/Night Switch | 1 | Each | 50 |
